25kW H-VHF DTV Channel Filter/Combiner Non Critical CIF 25kW

type

Combiners, VHF
  • Suitable for analog and digital TV or mobile media applications
  • Low VSWR
  • Temperature compensated
  • Dielectric is offering the CIF channel combiner with filters, tuned for mask filter requirements too



Notes:
1. Measured at 77ºF (25ºC), sea level, ) PSIG.
2. Group delay variation over the pass band.
3. By reducing the average input at NB input, half of the power reduced can be added to the WB input.
4. For more than 5,000 feet (1,524m), please contact the factory.

Floor mounting frame available; please contact factory.
*All specifications are subject to change
