TUA-M Broadband UHF Antenna
Type: Multi-Channel, Powerlite UHF, Television
Power Rating: 470
Mounting Options: Both
TUA-M Panel
- Operating Range: 470-860 MHz
- Horizontally polarized panel
- Economical broadband design
- Suitable for multiplexing many channels
- 7-16DIN input at the panel
- 1kW average power per panel
- Low VSWR 1.1:1 over the operating range
- Aluminum construction
- ABS radome for environmental protection
TUA-M panel in an array
- Key building block for antenna arrays
- 7 different standard azimuth patterns available
- Custom azimuth and elevation patterns available upon request
electrical specs table:
| Antenna Type |
Azimuth Pattern |
Layers |
Gain (ratio) |
Peak Gain (dBd) |
Weight (lbs) |
Avg. Power (kW) |
Antenna Height (ft) |
CaAc (CA=1.4) (ft^2) |
| TUA-C1-1/1M |
TUA-M-C1 |
1 |
12 |
10.8 |
25 |
0.5 |
3.2 |
6.8 |
| TUA-C1-2/2M |
TUA-M-C1 |
2 |
26.4 |
14.2 |
61.8 |
1 |
7 |
15.4 |
| TUA-C1-3/3M |
TUA-M-C1 |
3 |
40.8 |
16.1 |
89.1 |
1.5 |
10.8 |
23.1 |
| TUA-C1-4/4M |
TUA-M-C1 |
4 |
54 |
17.3 |
117.2 |
2 |
14.6 |
31.2 |
| TUA-C2-1/2M |
TUA-M-C2 |
1 |
5.8 |
7.6 |
61.8 |
2 |
3.2 |
13.3 |
| TUA-C2-2/4M |
TUA-M-C2 |
2 |
12.8 |
11.1 |
115.4 |
4 |
7 |
26.3 |
| TUA-C2-3/6M |
TUA-M-C2 |
3 |
19.7 |
12.9 |
170.8 |
6 |
10.8 |
40.1 |
| TUA-C2-4/8M |
TUA-M-C2 |
4 |
26.1 |
14.2 |
288 |
8 |
14.6 |
54.6 |
| TUA-C3-1/3M |
TUA-M-C3 |
1 |
3.8 |
5.8 |
87.7 |
2 |
3.2 |
17.4 |
| TUA-C3-2/6M |
TUA-M-C3 |
2 |
8.4 |
9.2 |
168.1 |
4 |
7 |
34.9 |
| TUA-C3-3/9M |
TUA-M-C3 |
3 |
12.9 |
11.1 |
251.2 |
6 |
10.8 |
53.5 |
| TUA-C3-4/12M |
TUA-M-C3 |
4 |
17.1 |
12.3 |
357 |
8 |
14.6 |
75.3 |
| TUA-T3-1/4M |
TUA-M-T3 |
1 |
3.2 |
5.1 |
87.7 |
1 |
3.2 |
15.5 |
| TUA-T3-2/8M |
TUA-M-T3 |
2 |
7 |
8.5 |
168.1 |
2 |
7 |
31 |
| TUA-T3-3/12M |
TUA-M-T3 |
3 |
10.9 |
10.4 |
251.2 |
3 |
10.8 |
47.8 |
| TUA-T3-4/16M |
TUA-M-T3 |
4 |
14.4 |
11.6 |
357 |
4 |
14.6 |
67.6 |
| TUA-S4-1/4M |
TUA-M-S4 |
1 |
3.8 |
5.8 |
113.6 |
1.5 |
3.2 |
21.5 |
| TUA-S4-2/8M |
TUA-M-S4 |
2 |
8.4 |
9.2 |
220.8 |
3 |
7 |
434 |
| TUA-S4-3/12M |
TUA-M-S4 |
3 |
12.9 |
11.1 |
351.6 |
4.5 |
10.8 |
68.9 |
| TUA-S4-4/16M |
TUA-M-S4 |
4 |
17.1 |
12.3 |
466 |
6 |
14.6 |
93.9 |
| TUA-P4-1/4M |
TUA-M-P4 |
1 |
5 |
7 |
113.6 |
2 |
3.2 |
21.5 |
| TUA-P4-2/8M |
TUA-M-P4 |
2 |
11 |
10.4 |
220.8 |
4 |
7 |
43.4 |
| TUA-P4-3/12M |
TUA-M-P4 |
3 |
17 |
12.3 |
351.6 |
6 |
10.8 |
68.9 |
| TUA-P4-4/16M |
TUA-M-P4 |
4 |
22.5 |
13.5 |
466 |
8 |
14.6 |
93.9 |
| TUA-O4-1/4M |
TUA-M-O4 |
1 |
2.6 |
4.1 |
113.6 |
1.5 |
3.2 |
21.5 |
| TUA-O4-2/8M |
TUA-M-O4 |
2 |
5.7 |
7.6 |
220.8 |
3 |
7 |
43.4 |
| TUA-O4-3/12M |
TUA-M-O4 |
3 |
8.8 |
9.5 |
351.6 |
4.5 |
10.8 |
68.9 |
| TUA-O4-4/16M |
TUA-M-O4 |
4 |
11.7 |
10.7 |
466 |
6 |
14.6 |
93.9 |
mechanical specs table:
| Mechanical Specifications- Individual Panel |
|
|
|
|
| Model |
Height (ft) |
Weight (lbs) |
Wind Area (ft^2) per TIA/EIA-222-F (Ca=1.4) |
Dimensions L x W x H (in) |
| TUA-M panel |
3.2 |
25 |
6.8 |
38.25 x 18.25 x 8.10 |
elevation images:
*All specifications are subject to change
