4-Port Motorized Switch Controller
type
Controllers and cables, Switches
- Allows control of one or two 2-ways switches
(coaxial or WR)
- Local, remote or lockout operation
- Adjustable delay in switching
12 V DC or 24 V DC voltage control relay selection
Notes:
For custom controllers, please contact the factory.
specification tables:
| Model Number DSC2 |
| Part Number 11000010590 |
| Dimensions (H x W x D) 5.25" x 19" x 8" (133.3mm x 482.6mm x 230mm) |
| AC Power Requirements 110-240 V AC/50-60 Hz |
| AC Power Consumption (Controller only) 40 W |
| Loading of Remote Control Contacts |
| Operating Voltage ≤ 27 V DC |
| Operating Current < 0.5 Amps |
| Loading of Interlock Contacts |
| Operating Voltage <0V DC OR <%0V AC |
| Operating Current <: |
|
| Control Relay Voltage 12 V DC, 24 V AC |
| Ambient Temperature 32⁰F (0⁰C) to 122⁰F (50⁰C) |
| Storage Temperature ₋4⁰F (₋20⁰C) to 158⁰F (70⁰C) |
| Storage/ Ambient Humidity 0-90% non condensing |
| Weight (with U-link) 12.5 lbs (5.7kg) |
*All specifications are subject to change
